- Product overview
- Characteristics
- Technical Parameter
It has the characteristics of short start time, fast leak detection speed, high sensitivity, strong ability to clear helium and no pollutant removal.
Compact structural design to facilitate integration into leak detection systems according to customer needs
Double iridium ion source, strong antioxidant capacity and long service life.
It has the characteristics of short start time, fast leak detection speed, high sensitivity, strong ability to clear helium and no pollutant removal.
Compact structural design to facilitate integration into leak detection systems according to customer needs
Double iridium ion source, strong antioxidant capacity and long service life.
Technical parameter
|
Minimum leak detection rate |
3×10-13 Pa·m3/s |
|
Maximum intake pressure |
≤1500 Pa |
|
Start time |
≤100 S |
|
Response time |
≤0.3 S |
|
Communication |
RS232,RS485,USB |
|
Calibration |
Internal automatic/external manual |
|
Language |
Chinese/English |
|
Interface dimensions |
DN KF25/DN KF16 |
|
Power / Voltage |
DC24V,240W |
|
Backing pump |
≥2.5L/S |
|
Weight |
22 Kg |
|
Size |
370*230*300 mm |
|
Work environment |
Temperature: 10-40 ℃ Humidity: ≤ 75% |
|
Detectable masses |
H2，He3，He4 |
